Details
We’ve all got tracks we love to play again and again. Whether you’re into double-black rock anthems or rhythm-section blues, the 4060 Z LT lets you keep hitting repeat thanks to the Shimano EP8 motor and long-lasting 720Wh battery. Riff off old favorites, create something new, hit play and repeat.
Specs
Frame | SCOR 4060 Z full carbon frame Lower-Link Driven Instant Center Linkage 160mm rear wheel travel Fully guided internal cable routing Boost 148 SRAM Universal Derailleur Hanger Lower ISCG 05 mount / Chainguide |
---|---|
Fork | FRONT SUSPENSION: Fox Float 38 Factory Series E-Bike | 170mm travel | Grip2 damper | Low & high speed compression adjust | Low & high speed rebound adjust | 44mm rake | E-MTB rated |
Rear Shock | Fox Float X Factory Series | Compression adjust | Rebound adjust | 2 position adjust | Bearing mount |
Rims/Wheels | DT Swiss H 1900 Spline | 30mm internal width | Tubeless ready |
Tires | Maxxis Assegai 29 x 2.5" (F) / Maxxis Dissector 29 x 2.4" (R) | Compound: 3C Maxx Grip (F) / 3C Maxx Terra (R) | Casing: EXO+ (F) / Double Down (R) | Tubeless ready |
Crankset | SHIMANO Deore XT (FC-M8150) | 165mm length | 34T chainring (SM-CRE80-12-B) |
Chain | SHIMANO Deore XT (CN-M8100) |
Rear Derailleur | SHIMANO Deore XT (SL-M8100-R) |
Rear Cogs | SHIMANO Deore XT (CS-M8100-12) | 10-51T |
Shifters | SHIMANO Deore XT (SL-M8100-R) |
Brakes | SHIMANO Deore XT | SHIMANO BR-M8120 calipers | SHIMANO BL-M8100 levers |
Saddle | Fizik Terra Alpaca |
Seat Post | Bikeyoke Divine | S 125mm. M/L 160mm. XL 185mm travel | Triggy Alpha lever |
* Subject to change without notice.
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Large | 30001615 | 210000096193 |
X-Large | 30001616 | 210000096195 |
